| Abrasion Resistance | Premium |
|---|---|
| Application | Hydraulic System Service With Petroleum And Water Based Fluids, For General Use. |
| Burst Pressure | 24000 psi |
| Color | Black |
| Conductivity | Conductive |
| Construction | 4 Spiral |
| Cover Material | Synthetic Rubber |
| Dash Size | 8 |
| Height | 1/2" |
| Hose Fittings | 4S |
| Impulse Cycle Life | 1000000 Cycles |
| Inside Dia. | 1/2" |
| Lay Line Style | Embossed |
| Length | 1 ft. |
|---|---|
| Max. Operating Temp. | 260°F |
| Min. Bend Radius | 7.09" |
| Min. Operating Temp. | -40°F |
| Outside Dia. | 24/25" |
| Package Form | Bulk |
| Reinforcement Material | Wire |
| Tube Material | Synthetic Rubber |
| Wall Thickness | 0.21" |
| Warranty | Hydraulics Warranty |
| Width | 1/2" |
| Working Pressure | 6000 psi |
| Height (cm) | 1.27 |
|---|---|
| Length (cm) | 30.48 |
| Width (cm) | 1.27 |
| HS Code | 4009220050 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.2655 |
| Style | Model | Dash Size | Min. Bend Radius | Burst Pressure | Inside Dia. | Temp. Range | Cover Material | Tube Material | Reinforcement | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | GH493-12 | 12 | 9.45" | 22000 psi | 3/4" | - | Synthetic Rubber | Synthetic Rubber | - | $1,706.58 | |
| A | GH493-16 | 16 | 11.81" | 20400 psi | 1" | - | Synthetic Rubber | Synthetic Rubber | - | $1,971.27 | |
| A | GH493-20 | 20 | 16.54" | 18000 psi | 1 1/4" | - | Synthetic Rubber | Synthetic Rubber | - | $2,538.89 | |
| A | GH493-10X50' | -10 | - | - | - | -40° to +260° | Synthetic Rubber | Synthetic Rubber | (4) Spiral Wire | $1,704.06 | |
| A | GH493-20X60FT | -20 | 8 1/4" | - | - | -40° to +260° | Synthetic Rubber | Synthetic Rubber | (4) Spiral Wire | $3,535.28 | |
| A | GH493-24X60FT | -24 | 10" | - | - | -40° to +260° | Synthetic Rubber | Synthetic Rubber | (4) Spiral Wire | $4,547.62 | |
| A | GH493-32X60FT | -32 | 12 1/2" | - | - | -40° to +260° | Synthetic Rubber | Synthetic Rubber | (4) Spiral Wire | $6,401.04 |
