Thread Size | Length | Drill Point Size | Drive Size | Head Height | Head Dia. | Tip Length | Maximum Thickness | Pkg. Qty. | Price |
---|---|---|---|---|---|---|---|---|---|
#6-20 | 1/2" | 2 | #2 | 0.097" | 0.27" | 3/16" | 0.068" | 100 | $3.13 |
#6-20 | 5/8" | 2 | #2 | 0.097" | 0.27" | 3/16" | 0.19" | 100 | $22.13 |
#6-20 | 3/4" | 2 | #2 | 0.097" | 0.27" | 3/16" | 0.068" | 100 | $8.61 |
#8-18 | 1/2" | 2 | #2 | 0.11" | 0.322" | 7/32" | - | 100 | $4.44 |
#8-18 | 5/8" | 2 | #2 | 0.115" | 0.322" | 7/32" | 0.068" | 100 | $4.02 |
#8-18 | 3/4" | 2 | #2 | 0.11" | 0.322" | 7/32" | - | 100 | $9.01 |
#8-18 | 1" | 2 | #2 | 0.11" | 0.322" | 7/32" | - | 100 | $5.09 |
#8-18 | 1 1/4" | 2 | #2 | 0.115" | 0.322" | 7/32" | 0.068" | 100 | $6.96 |
#8-18 | 1 1/2" | 2 | #2 | 0.115" | 0.322" | 7/32" | 0.068" | 100 | $7.81 |
#10-16 | 1/2" | 2 | #2 | 0.133" | 0.373" | 15/64" | 0.068" | 100 | $5.56 |
#10-16 | 3/4" | 2 | #3 | 0.133" | 0.373" | 15/64" | 0.068" | 100 | $6.54 |
#10-16 | 1" | 2 | #2 | 0.133" | 0.373" | 15/64" | 0.068" | 100 | $12.10 |
#10-16 | 1 1/4" | 2 | #2 | 0.133" | 0.373" | 15/64" | 0.068" | 50 | $9.56 |
#10-16 | 1 1/2" | 3 | #2 | 0.128" | 0.373" | 15/64" | - | 50 | $10.47 |
#12-14 | 3/4" | 3 | #3 | 0.145" | 0.425" | 9/32" | - | 50 | $9.46 |
#12-14 | 1" | 2 | #3 | 0.145" | 0.425" | 9/32" | - | 50 | $5.24 |
#12-14 | 1 1/4" | 2 | #3 | 0.145" | 0.425" | 9/32" | - | 50 | $5.67 |
#12-14 | 1 1/2" | 2 | #3 | 0.145" | 0.425" | 9/32" | - | 50 | $7.90 |
1/4"-14 | 1" | 2 | #3 | 0.168" | 0.492" | 5/16" | - | 50 | $10.73 |
1/4"-14 | 1 1/4" | 2 | #3 | 0.169" | 0.476" | 5/16" | 0.068" | 25 | $8.28 |
1/4"-14 | 1 1/2" | 2 | #3 | 0.169" | 0.476" | 5/16" | 0.068" | 25 | $4.76 |
1/4"-14 | 1 1/2" | 2 | #3 | 0.169" | 0.476" | 5/16" | 0.068" | 1 | $221.83 |
1/4"-14 | 2" | 2 | #3 | 0.169" | 0.476" | 5/16" | 0.068" | 25 | $5.79 |
Thread Size | Length | Drill Point Size | Drive Size | Head Height | Head Dia. | Tip Length | Maximum Thickness | Pkg. Qty. | Price |
---|---|---|---|---|---|---|---|---|---|
#6-20 | 1/2" | 2 | #2 | 0.083" | 0.262" | 3/16" | - | 100 | $2.31 |
#6-20 | 5/8" | 2 | #2 | 0.083" | 0.262" | 3/16" | 0.19" | 100 | $6.98 |
#6-20 | 3/4" | 2 | #2 | 0.083" | 0.262" | 3/16" | - | 100 | $3.00 |
#6-20 | 1" | 2 | #2 | 0.083" | 0.262" | 3/16" | - | 100 | $9.58 |
#8-18 | 3/4" | 2 | #2 | 0.1" | 0.312" | 7/32" | 0.068" | 100 | $7.54 |
#8-18 | 1" | 2 | #2 | 0.1" | 0.312" | 7/32" | 0.068" | 100 | $9.67 |
#8-18 | 1" | 2 | #2 | 0.1" | 0.312" | 7/32" | 0.068" | 5 | $698.65 |
#8-18 | 1 1/4" | 2 | #2 | 0.1" | 0.312" | 7/32" | - | 100 | $6.56 |
#8-18 | 1 1/2" | 2 | #2 | 0.1" | 0.312" | 7/32" | - | 3 | $326.78 |
#8-18 | 1 1/2" | 2 | #2 | 0.1" | 0.312" | 7/32" | - | 100 | $6.43 |
#8-18 | 2 1/4" | 3 | #2 | - | 0.395" | 9/64" | - | 2 | $695.72 |
#8-18 | 2 1/4" | 3 | #2 | 0.11" | 0.395" | 9/64" | - | 100 | $21.63 |
#10-16 | 1" | 2 | #3 | 0.116" | 0.362" | 15/64" | 0.068" | 100 | $10.29 |
#10-16 | 1 1/4" | 2 | #2 | 0.116" | 0.362" | 15/64" | 0.068" | 50 | $8.76 |
#10-16 | 1 1/2" | 2 | #2 | 0.116" | 0.362" | 15/64" | 0.068" | 50 | $8.69 |
Thread Size | Length | Drill Point Size | Drive Size | Head Height | Head Dia. | Washer O.d. | Tip Length | Pkg. Qty. | Price |
---|---|---|---|---|---|---|---|---|---|
#8-18 | 1/2" | 2 | 1/4" | 0.103" | - | 0.348" | 7/32" | 100 | $9.14 |
#8-18 | 5/8" | 2 | 1/4" | 0.11" | 0.25" | 0.348" | 7/32" | 100 | $5.58 |
#8-18 | 3/4" | 2 | 1/4" | 0.103" | - | 0.348" | 7/32" | 100 | $10.60 |
#8-18 | 1" | 2 | 1/4" | 0.103" | - | 0.348" | 7/32" | 100 | $6.94 |
#8-18 | 1 1/4" | 2 | 1/4" | 0.11" | 0.25" | 0.348" | 7/32" | 100 | $14.53 |
#8-18 | 1 1/2" | 2 | 1/4" | 0.11" | 0.25" | 0.348" | 7/32" | 100 | $17.31 |
#10-16 | 1/2" | 2 | 5/16" | 0.112" | - | 0.414" | 15/64" | 100 | $7.48 |
#10-16 | 5/8" | 2 | 5/16" | 0.12" | 0.312" | 0.414" | 15/64" | 100 | $13.74 |
#10-16 | 3/4" | 2 | 5/16" | 0.12" | 0.312" | 0.414" | 15/64" | 100 | $7.69 |
#10-16 | 3/4" | 2 | 5/16" | 0.12" | 0.312" | 0.414" | 15/64" | 3600 | $776.10 |
#10-16 | 1" | 2 | 5/16" | 0.112" | - | 0.414" | 15/64" | 100 | $11.54 |
#10-16 | 1 1/4" | 2 | 5/16" | 0.12" | 0.312" | 0.414" | 15/64" | 50 | $9.92 |
#10-16 | 1 1/2" | 2 | 5/16" | 0.12" | 0.312" | 0.414" | 15/64" | 50 | $10.36 |
#12-14 | 3/4" | 3 | 5/16" | 0.155" | 0.312" | 0.432" | 23/64" | 50 | $8.53 |
#12-14 | 3/4" | 3 | 5/16" | 0.155" | 0.312" | 0.432" | 23/64" | 2 | $377.86 |
#12-14 | 1" | 3 | 5/16" | 0.155" | 0.312" | 0.432" | 23/64" | 50 | $9.33 |
#12-14 | 1 1/4" | 3 | 5/16" | 0.155" | 0.312" | 0.432" | 23/64" | 50 | $13.13 |
#12-14 | 1 1/2" | 3 | 5/16" | 0.147" | - | 0.432" | 9/32" | 50 | $13.68 |
#12-14 | 2" | 3 | 5/16" | 0.155" | 0.312" | 0.432" | 23/64" | 25 | $4.19 |
1/4"-14 | 3/4" | 3 | 3/8" | 0.181" | 0.25" | 0.52" | 5/16" | 50 | $15.33 |
1/4"-14 | 1" | 3 | 3/8" | 0.181" | - | 0.52" | 5/16" | 50 | $13.83 |
1/4"-14 | 1 1/4" | 3 | 3/8" | 0.181" | 0.25" | 0.52" | 5/16" | 25 | $9.39 |
1/4"-14 | 1 1/2" | 3 | 3/8" | 0.19" | 0.375" | 0.52" | 25/64" | 25 | $10.10 |
1/4"-14 | 2" | 3 | 3/8" | 0.181" | - | 0.52" | 5/16" | 25 | $12.89 |
1/4"-14 | 2 1/2" | 3 | 3/8" | 0.19" | 0.375" | 0.52" | 25/64" | 670 | $524.97 |
1/4"-14 | 2 1/2" | 3 | 3/8" | 0.19" | 0.375" | 0.52" | 25/64" | 10 | $6.42 |
